Model SR-FSK-40VI



This machine is widely used in food, medicine, health-care product industries for packaging granule products, such as sugar, salt, chicken powder, instant coffee, medicine, broken tea, ect.

It can realize automatic measuring, bag forming, filling, sealing, cutting, counting, etc., and meet cutomer's personalized packaging requirement such as nitrogen gas flushing, dust exhausting, cooling, link bag, cartoning, etc.



1. Adopt full servo motor driving system: sealing, film pulling and cutting, each process is controlled by one separated servo motor for precise actions and high-speed, the highest packing speed can be up to 150 bags per minute.

2. Panasonic PLC with color touch screen, quick and convenient adjustment of relevant production parameters.

3. Adopt movable feeding system, which could keep product intact without damage, guarantee measuring accuracy and assure adjustment more convenient plus much simpler cleaning job.

4. Unique sealing system avoids bag leakage and wrinkle, guarantees sealing margin flat and neat, to present beautiful packing effect.

5. Patented sealing system, L-shape sealing design can realize vertical sealing and horizontal sealing synchronously, greatly reduce sealing time and improve packaging speed.

6. Servo motor driven sealing part can make sure sealing pattern uniform and clear, sealing area flat and beautiful, no leakage or wrinkle for good air tightness.

7. External cuuter allows quick, convenient and safe adjustment of cutting position while the machine keeps running, no need to stop the machine.

8. Double cutters as option, can achieve chain bag ( link bag ) function, greatly reduce labor intensity in cartoning work and assure accurate bags in each carton.

Main technical parameters

                         Bag Size

             L:55-120 mm  W:40-90 mm

                     Max Capacity

                      150 bags/min

               Maximum Filling Range

                           40 ml


                 220 V, 50 HZ, 3.5 kW


                          450 Kgs

                Dimension (L*W*H)

                 1100*1000*2300 mm

 Depending on product property and filling volume
